    RFCTHERM-340(DBT)

    CAS #: 26898-17-9

    Product Description

    RFCTHERM-340, also called as RFCTHERM-DBT, has a single molecular structure and high purity, its main ingredient is Dibenzyltoluene(abbrev: DBT), it is a high temperature liquid phase heat transfer fluid with excellent thermal stability. RFCTHERM-340 was developed for use at temperatures up to 340 in liquid phase heat transfer systems, Very high resistance to oxidation as well as high resistance to sludge and fouling can result in a significant reduction in capital investment, and reduced utility and maintenance costs as compared with other pressurized systems using more volatile high temperature heat transfer fluids. its chemical equivalent to TOTAL Jarytherm DBT and SOKEN NeoSK 1400.

    The Temperature Range for use

    Liquid: -30 to 340

    Applications

    It can be used in a wide variety of industries, such as:

    · Chemicals

    · Refining

    · Oil and Gas Processing

    · Switch Condensers

    · Pharmaceuticals Manufacturing

    · Specialty and Batch Chemical Production

    Typical Properties

    Property

    Standard

    Appearance

    Colorless or pale yellow transparent liquid

    Density g/cm3 (20)

    1.035-1.045

    Kinematic Viscosity mm2/S(40)

    1020

    Water(mg/Kg)

    100

    Crystal Point

    ≤-30

    Maximum Film Temperature

    425

    Normal Boiling Point

    ≥391

    Flash Point

    ≥200

    Auto-ignition Temperature

    ≥500

    Residual Carbon(wt%)

    Maximum Use Temperature

    340

    The Permission Maximum Temperature

    380

    Expansion coefficient(cc/cc)

    8.7×10

    Pumpability

    -20

    Heat(Kcal/kg. )

    0.578

    Thermal conductivityKcal/m.h

    0.09

    Vapor pressure(mmHg)

    5

    Average Molecular weight

    270

    S

    ≤5ppm

    CL

    ≤10ppm
